Function:
REGISTRATION AND OFF-CONTACT SYSTEM
1.U-slot guide locator system
2.Precise four-point pallet height adjustable system, offering wide range of off-contact adjustment
3.Print head lock-in design maintains exact color-to-color repeatability but ensuring +/-0.10mm registration
SCREEN CLAMPS & HOLDERS
1.Built with a low profile and release height adjustable arms, reducing operators fatigue and downtime
2.Three large-size knobs secure screen frame tightly
3.Appliable in various frame sizes up to 500mm wide
4.Two-spring hinge system increases the print speed
PALLET SYSTEM
1.Special resin made pallets provide a durable, effective print surface
2.Accommodate all types of pallets adhesives
3.Easy-to-install feature combined with left-and-right adjustment
4.Available in any special requirements
HEAVY DUTY CONSTRUCTION
1.Tapered roller bearings designed for easy spinning
2.Duo-deck system speeds up print production
3.Unique cabinet base support provides absolute stability and a spare space for multi-use
4.Heavy duty frame construction for durability and minimum flex
MODELS AND BUSINESS OPPORTUNITY
1.Print production made up to 700 pcs/hour
2.Unlimited growth opportunity
3.Requires no special skill or education-easily operated by anyone
Technical parameter:
1. printing colors:8colors
2. Max.printing area:400*500mm
3. Worktable area:450*550mm
4.Each Movable Dryer Power:6kw
5.Size:280×280×135cm
6.weight:360kg
