Application:

It is widely used for curing in cellphone crust, compact disc, thin film switch, electronic and plastic crust UV surface to painting, kinds of UV paint, IMD injection products curing,electronic components, liquid crystal film, terminal gumming,hardware parts,plastic accessories,paper, glass,cellphone parts sticking and LCD etc.All products width within 200mm.

Technical Parameter:

outside dimension:850*500*850mm   Weight: 90KG
The length of inlet:170mm  The length of output:170mm  The width of belt:200mm
The height of inlet:232mm
The hetght of inlet point:50mm (adjusting is OK)
The material of belt:teflon (imported)
Light tube power:2.0KW*1pcs (the height of light shine can be adjusted)
The width of light shine:200mm
The length of shine area:200mm
The strength of shine:100W/cm
The distance of shine:120-190mm (adjustion)
Type of cooling: exhausting by air cooling
The value of wave crest:365nm
Settling time:about 3 min  Convey motor:15W
Life 1,000 h (making sure 800h)
Decorative style:injection
Exhaust fan:20W-1 set, 40W-1 set Gross wattage:2.2KW
Convey speed:0-12m/min
Power supply:single phase 220v
