(GW-4F-UV) 4 color flat bed automatic screen printing machine

  • Model number:GW-4F-UV
  • Printing area:300*200 MM
  • Printing speed:2100 pieces per hour
  • Machine size:2000mm*1420mm*1750mm
  • Gross weight:1000 kgs
  • MOQ:1 set
  • Payment terms:T/T,Western Union,Paypal,L/C
  • Package way:plywood
  • Delivery way:by sea or by air
  • Lead time:within 20days

full automatic 4 color flat screen printing machine

the machine can print mass single to multicolor flat product,such as square,rectangle.board,
The new transmission system consisted of advanced imported  motor,speed converter device and pneumatic component which has the function of electrodeless variable-speed,synchronous  transmission ,auto allocation and no-work piece-no –printing.

                  Main function of this machine:
                  ⊕ Auto feeder
                  ⊕ Automatic loading direction-selectionsystem
                  ⊕ Auto flame treatment for container surface
                  ⊕ Electrodeless variable-speed motor system
                  ⊕ Adjustable mechanical synchronous transfer system
                  ⊕ Auto pre-allocation system
                  ⊕ UV-coating system

                  Main parts:
                  ⊕ Machine main motor:MOTOVARIO
                  ⊕ PLC:OMRON
                  ⊕ Photoeletric switch:OMRON
                  ⊕ Touch screen:KINCO
                  ⊕ Button switch:APT
                  ⊕ Contactor:SCHNEIDER
                  ⊕ Relay: OMRON
                  ⊕ Frequency converter: PANASONIC
                  ⊕ UV coating system:HONOVIA
                  ⊕ Pneumatic components:SMC/AIRTAC

 technical parameter:

printing area of product:L300mm*W200mm*H200mm
printing speed:2100pcs/hour
electric:3P AC 380V 50/60Hz
power:7.5KW
air compress:6~8bar
size of machine:2000mm*1420mm*1750mm
net weight:1000 kg
